Marley SolarTile®

Solar Roof Tiles act as both a roof covering and electricity generating solution.
grey breaker

Marley SolarTile roof panels replace standard roofing tiles or slates, giving you the benefit of both a weatherproof roof covering and electricity generating solution. They enhance design possibilities, creating sleek aesthetics and provide industry-leading wind and fire performance. What's more, we offer both a 25 year panel efficiency guarantee, and when used as part of complete Marley Roof System, a 15 year warranty on the full system for added peace of mind.

roof system warranty

Why Choose Marley SolarTile®?


Carrying an independent assessment of durability, the entire roof integrated solar system can be demonstrated to satisfy the NHBC Technical Requirements

Complete Solar Roof System - Complete Peace of Mind

With Marley SolarTile®, the integrated solar roof system has come of age to support homeowners looking to reduce the cost of running their homes.

Marley SolarTile® alone offers market leading wind and fire resistance, but when combined with the complete Marley Roof System, the security of a roof that works to keep the weather out, also works to generate power for the home.

solar panels within Marley roof
clay roof tiles with solar

Flush fit for enhanced kerb appeal

Marley SolarTile® is designed to form an integral part of the fabric of the roof.

Fixed directly onto the battens to replace a section of roof tiles or slates means a completely flush fit can be achieved, to provide a sleek, unobtrusive roof finish.

What's more, with no space behind the panels for birds to nest, Marley SolarTile® remains a very low maintenance, high performance solar solution.

Carefully designed for quick and easy installation

Colour-coded flashing kits makes Marley SolarTile® simple and fast to install, removing the confusion and cost of added materials on the roof.

For new roofs or extensions to existing buildings, regulations require that all tiles are fixed with nails or clips. Roof integrated solar panels, like Marley SolarTile®, can be installed easily in a new roof application. The solar panels and flashings can be fitted to the roof first and then the roof covering can be fixed around them.

roofers installing solar panels
grey breaker

The Marley SolarTile® Range

M10 405Wp Solar Panel

Larger than Marley’s 335Wp panel, the new M10 Solar Photovoltaic Panel delivers a peak power of 405Wp to increase total power from a roof area, whilst allowing for the installation of fewer solar panels to achieve the desired power output.

405 solar panel standing
Mechanical Specification

Aperture area 1.885m²
Width (across roof) 1134mm
Height (up roof) 1722mm
Thickness 70mm
Weight 25kg
Static roof loading (distributed) 12.8kg/m² (distributed)
Characteristic wind resistance 4.24kPa
Ultimate design load 4.24kPa
Positive design load (IEC 61215) 5.40kPa
Fire rating (EN 13501-5) Broof (T1, T2, T3, T4)
Systems Warranty (compatibility/ weathertightness) 15 years
Power warranty (% rated)

90% - 10 years

80% - 25 years

Standards IEC61215, 61730, TUV, MCS05, MSC12


Electrical Specification

Model PV16-405-M10
Marley Product Code MAPV16-405-M10
Peak Power 405Wp
Efficiency 21.5%
No. of cells 54x2
Max. power voltage (Vmpp) 31.02V
Max. power current (Impp) 13.06A
Open circuit voltage (Voc) 37.05V
Short circuit current 9 (Isc) 13.62A
NOCT* 45°C
Cell type Monocrystalline Silicon
Power temperature co-efficient -0.35% /°C
Current temperature co-efficient -0.05% /°C
Voltage temperature co-efficient -0.28% /°C
Max. system voltage 1000VDC
Safety classification Class II

335Wp Solar Panel

The 335Wp panel is now well recognised in the industry, and on properties throughout the UK and Europe. A Perfect solution for domestic properties with smaller roof areas, or obstacles in the roof such as dormers or roof windows.

335 solar panel standing
Mechanical Specification

Aperture area 1.622m²
Width (across roof) 1000mm
Height (up roof) 1686mm
Thickness 69mm
Weight 21.7kg
Static roof loading (distributed) 12.9kg/m² (distributed)
Characteristic wind resistance 5.32kPa
Ultimate design load 5.32kPa
Positive design load (IEC 61215) 5.40kPa
Fire rating (EN 13501-5) Broof (T1, T2, T3, T4)
Systems Warranty (compatibility/ weathertightness) 15 years
Power warranty (% rated)

90% - 10 years

80% - 25 years

Standards IEC61215, 61730, TUV, MCS05, MSC12


Electrical Specification

Model PV16-335-G1
Marley Product Code MAPV16-335-G1
Peak Power 335Wp
Efficiency 20.7%
No. of cells 60x2
Max. power voltage (Vmpp) 34.7V
Max. power current (Impp) 9.7A
Open circuit voltage (Voc) 37.3V
Short circuit current 9 (Isc) 10.3A
NOCT* 44°C
Cell type Monocrystalline Silicon
Power temperature co-efficient -0.38% /°C
Current temperature co-efficient -0.05% /°C
Voltage temperature co-efficient -0.30% /°C
Max. system voltage 1000VDC
Safety classification Class II


Designed for new build and refurbishment on existing buildings
An ideal choice for both roof refurbishments and new-build projects, Solar pv roof tiles are provide an uncluttered aesthetic with no visible brackets or racking, as well as easy maintenance and our market-leading 15-year guarantee.

Marley SolarTile® can be fitted as part of a typical roofing project and installation is fast. Thanks to the patented push-together design, installation times for your solar rooftop can be less than one hour per kilowatt peak.
All in the panel details

Installed in either a landscape or portrait orientation, Marley SolarTile® panels are easily combined using patented push-fit technology to create solar arrays of any shape and size. As well as this, the industry leading 5mm panel spacing and hidden fixings give a high-end, sleek aesthetic to your solar roof.

Panel performance
Marley SolarTile® is the only roof-integrated solar system accredited with the highest resistance to spread of flame and fire penetration in all European fire safety tests, achieving BRoof T1, T2, T3 and T4.

The PV solar tiles also provide excellent weather-tightness and wind resistance, without the need for extra roof batten support, adhesive flashing rolls or fireproofing materials. The certified wind resistance for Marley SolarTile® is more than four times higher than competitor PV roof tiles and is suitable for even the most exposed locations.

Marley SolarTile® is compatible with the entire range of Marley roof coverings, including clay and concrete tiles and cedar shingles and shakes, and it is suitable for installation on low-pitch roofs.
grey breaker

Solar Case Studies

Take a look

Discover examples of other projects throughout the UK that have used our Marley SolarTile® solution

grey breaker

Supporting Solar Specification

Useful tools to help with your solar project

grey breaker

Installation

See how simple it is to install the Marley SolarTile® system.

The solar panels and flashings can be fitted to the roof first and then the roof covering fixed around them. Integrated solar panels are also easy to install as a retrofit option. Simply remove the necessary section of roof tiles or slates, and replace with the solar panels. All that is left is to retile up to the flashings for a fully roof integrated solution.

grey breaker

Technical Performance

trees in forest with sun shining through

Biodiversity

For every five solar panels sold as part of the Marley Group, we support the planting of a tree through charitable organisations across the world.

Known as the #FusionForest, this collaborative approach supports the long term rehabilitation of natural ecosystems by teaming up with organisations with local expertise.
